Zurcon® - L-Cup - RL08N0250-Z22
Zurcon® L-Cup® is a single acting polyurethane rod seal with a unique design offering a hydrodynamic backpumping ability over the complete working pressure range.
Rod/L-Cup®/Zurcon®:
Groove Diameter Outside 33 mm
Signature Standard RL08N0250-Z22
Quality (10th Digit) -
TSS Article Number (3 to 9) 08N0250
Type of Article 0
Root Groove Inside Diameter 25 mm
Root Groove Outside Diameter 33 mm
Groove Diameter Inside 25 mm
Root Groove Width 6.300000000000000 mm
Article Group RL
Groove Width 6.300000000000000 mm
Compound code Z22
